International Tolerance Standards for Stainless Steel Sheet Sizes
In adherence to international acceptance standards, stainless steel sheets are manufactured with specific dimensions and weight parameters. The following specifications outline the permissible range for thickness, nominal width, and maximum weight per unit width:
- Thickness Range (mm): 2.5 – 10.00
- Nominal Width Range (mm): 915 – 1524
- Maximum Weight (kg/mm width): 22
| Item | Stainless Steel Coil(Hot rolled, cold rolled) |
|---|---|
| Inner Diameter | 610 +0/-5 mm |
| Width | 915~1524 mm |
| Thickness | 2.5~10.0 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Material | SS 202 Coils, SS 304 Coils, SS 316 Coils, SS 321 Coils, SS 310 Coils , SS 410 Coils, SS 420 Coils, SS 416 Coils |
| Surface | 2D, etching, 8K, 2B, BA, NO.4, hair line,NO.1, NO.8, Brush, checkered, mirror,embossed, sand blast etc |
| Standard | ASTM A240, ASTM A167, JIS4304-2005, GB/T3280-2007, EN10088-2-2005, etc |
Stainless Steel Hr Coil Unit Weight Limitation:
| Unit: ton | 5 feet | 1M | 3 feet | 4 feet |
|---|---|---|---|---|
| 300 series | – | – | – | 3~22 |
| 300 series | 3~23 (≦5.0) / 27 (>5.0) | 3~18 | 3~17 | 3~22 |
| Remark | Both Cut Edge and Mill Edge are available |
Important Consideration
What is Included
Yes, the specifications provided are general and may vary based on the grade and finish of the stainless steel product. It is recommended to consult with your nearest commercial agent for specific details regarding variations in dimensions and weight parameters.
Yes, there may be other sizes or specifications beyond the mentioned range. For comprehensive information, individuals are encouraged to reach out to their nearest commercial agent, who can provide details on the diverse options available.
For inquiries regarding stainless steel grades not explicitly mentioned, individuals can contact the provided email address: For inquiries regarding stainless steel grades not explicitly mentioned, individuals can contact the provided email address: [email protected]. This email serves as a direct point of contact for obtaining information on additional stainless steel grades.. This email serves as a direct point of contact for obtaining information on additional stainless steel grades.
With decades of experience, we take pride in offering a unique range of stainless steel bars, rebars, metal pipes, steel plates, and more.
